    Polycarbonate Housing SMD2835 1200mm LED Tri Proof Lights Easy Installation

    Ask Lasest Price
    Brand Name : FYTLED
    Model Number : 40W~80W
    Certification : UL DLC CE RoHS
    Price : US16/PCS
    Payment Terms : T/T, D/P
    Supply Ability : 1000 PCS per day
    Delivery Time : 8-9 work days
    • Product Details
    • Company Profile

    Polycarbonate Housing SMD2835 1200mm LED Tri Proof Lights Easy Installation

    E-max tri-proof light T55 Easy installation to save labor cost IP65 ​

    Aluminum PCB with a high thermal Conductivity with LM80 SMD2835 LED chips.
    The polycarbonate housing is cast from a single mold (cover cannot be removed) and therefore absolutely dust and water proof with an IP65 rating.

    The massive internal aluminum housing provides excellent heat dissipation and maximum stability.


    Features
    -40W/60W/80W

    -1200mm/1500mm/2400mm

    -130lm/w
    -Very easy installation to save labor cost
    -IP65 protection
    -5 years warranty



    OPTIONS

    -CRI90 available upon request
    -High quality led driver, flicker free driver is optional



    AREA OF APPLICATION

    -Corridors / hallways
    -Storage areas
    -Stairways
    -Parking lots
    -Gas stations,
    -Car wash / auto body operations
    -Other applications subject to harsh, wet, or otherwise challenging conditions


    CERTIFICATIONS
    North American market: UL, DLC
    European market: CE (EMC, LVD, RoHS)
    INCLUDED MOUNTING ACCESSORY
    (Surface mounting bracket is optional)
    Product Specification
    MODEL No.Specifications
    Size (mm.)Rated PowerInput VoltageLED QuantityColor TemperatureRated luminous efficacy (lm/W)Luminous fluxCRIBeam AngleIP GradeDriver Brand
    T55-40W121057*53*60.5mm40WAC 100~277V
    50~60Hz
    126PCS SMD28353000K/4000K
    5000K/6000K
    130±105200±400lm>80120°IP65Tomcarline
    T55-60W121057*53*60.5mm60W171PCS SMD28357800±600lm
    T55-60W151337*53*60.5mm60W171PCS SMD28357800±600lm
    T55-80W242490*70*70mm80W252PCS SMD283510800±800lm
    Electrical data&Photometrical data
    Operating frequency47-63HZAvailable light colorswarm white;natural white;daylight white
    Type of currentAC100-277VAvailable color temperatures3000K;4000K;5000K;6000K
    Power factor λ>0.9Color rendering index Ra>80
    Efficiency in %>92%Standard deviation of color matching<5
    Start time (0.2s / 0.5s / … )0.1SUGR (Unified Glare Rating)<25
    Warm-up time to 60 % (1.5s / 2s / … )0.5SAvailable beam angles120°

    LEAD TIME
    5-7 days for sample
    2-4 weeks for bulk order
    Polycarbonate Housing SMD2835 1200mm LED Tri Proof Lights Easy InstallationPolycarbonate Housing SMD2835 1200mm LED Tri Proof Lights Easy InstallationPolycarbonate Housing SMD2835 1200mm LED Tri Proof Lights Easy InstallationPolycarbonate Housing SMD2835 1200mm LED Tri Proof Lights Easy Installation
    FAQ:
    1,Prices conditions
    Price can be FOB, CIF ,EXW, or With taxes
    2,What will be the delivery time and what will be the mode of payment?
    About 4-7days. Butif you want a specialsample, it will need some times to make the mold.
    The payment can be T/T transaction,Letter of credit,Paypal,Western Union
    3,Could you please send me the sample for the same.So that i could see and analyze its quality?
    Yes.We can send samples first,samples need to be charged if the value is higher.
    4,Will there be any contract for this business or trade?
    Yes,there is a normal PI before the order is placed.
