    320mm IP65 rating High Bay Dimmable Led Lights Dual DIP Switch

    Ask Lasest Price
    Brand Name : FYTLED
    Model Number : HB07 100W-150W-200W CCT adjustable
    Certification : UL, CUL, DLC,CE(EMC,LVD), RoHS,
    Price : US40-65/pcs
    Payment Terms : L/C,, T/T, OA,
    Supply Ability : High Bay Series: 30000 pcs/month
    Delivery Time : 3-5days for sample production
    • Product Details
    • Company Profile

    320mm IP65 rating High Bay Dimmable Led Lights Dual DIP Switch

    IP65 IK10 Dual DIP switch HB07 Hero UFO highbay UL, DLC, SAA, CE certification with black Housing at the 5-year warranty


    Benefits

    • Power and CCT adjustable by DIP switches, it really helps you to save your SKU and cash flow.
    • 200W can be adjusted to 150W, 100W.
    • High Efficiency up to 140lm/w
    • Durable and compact low-profile housing design
    • IP65 for indoor and outdoor applications
    • 5-year warranty

    Features

    • 3030 SMD LED, luminaire light efficiency 140lm/w

    • Mean well driver, IP65 and 5 years warranty

    • Aluminum heatsink with fins, bigger heat radiating area

    • With big aluminum PCB and SMD, better heat dissipation

    • Consistent color rendering (CRI) > 80

    Warranty: 5 years


    320mm IP65 rating High Bay Dimmable Led Lights Dual DIP Switch320mm IP65 rating High Bay Dimmable Led Lights Dual DIP Switch320mm IP65 rating High Bay Dimmable Led Lights Dual DIP Switch


    Options

    • Optional Meanwell, MOSO driver available

    • Milky PC cover available upon request

    • Microwave motion sensor/ daylight sensor available

    • With big aluminum PCB and SMD, better heat dissipation

    • Consistent color rendering (CRI) > 80


    Product Specification

    Specification for 140lm/w IP65 black round ufo highbay led 200w

    General

    Information

    Product Typehighbay led 200W(DIP Design)
    Product Sizeφ320*188mm
    Product ColorBlack
    Electric parameterDriver BrandTomcarline driver/ Meanwell optional
    Input VoltageAC200-240V
    Power200W-150W-100W
    PF>0.9
    Optical ParameterLED BrandEMC 3030
    CRI>80
    Color Temperature (CCT DIP)① 3000K+4000K
    ② 3000K+5000K
    ③ 3000K+6000K
    ④ 4000K+5000K
    ⑤ 4000K+6000K ⑥ 5000K+6000K
    Luminous Flux200W:28000±2000lm,150W:21000±1500lm,100W:14000±1000lm
    Luminous Efficiency140lm/w
    Beam angle60°/90°/110°
    OthersLifetime50,000Hr
    Operating temperature-40℃~50℃
    Warranty5 years
    MaterialsAL housing+PC lens
    InstallationSuspending/Surface mounting
    ApplicationIndustry, warehouse, station, gymnasium

    Area of application
    • Industrial Facility
    • Exhibition Center
    • Shopping Mall
    • Gymnasium
    • Airport
    • Toll Station and so on.

    FAQ

    1. Q: Where is your target market?

    A: Europe is our main market, followed by North America, Asia, Australia and South America have our customers. Our products have CE, Rohs, TUV, ENEC, UL, CUL, DLC, SAA and other certifications, I believe it can meet your needs.


    2. Q: What is your MOQ?

    A: We support purchasing samples to check the quality. When you buy samples, MOQ is 1Pcs.

    3. Q: How long is the sample production time?

    A: About 4-7days. Butif you want a specialsample, it will need some times to make the mold.


    4. Q: What is the Payment?

    A: For new customers,usually we adopt the T/T, and we have 2 ways:
    1) T/T 100%

    2) 30% advance deposit, the Balance should be paid off before shipment.
    As our cooperation deepens, we can discuss other payment terms


    5. Q:How long is the delivery time?

    A: About 7 days
