Brand Name : | FYTLED |
Model Number : | T54 |
Certification : | EMC LVD RoHS |
Price : | US 9.99/PCS |
Payment Terms : | T/T, Western Union, L/C |
Supply Ability : | 1200 PCS per day |
Delivery Time : | 10-15 work days |
Key Features
-20W~40W
OPTIONS
-CRI90 available upon request
AREA OF APPLICATION
MODEL No. | Specifications | ||||||||
Size (mm.) | Rated Power | LED Quantity | Color Temperature | Rated luminous efficacy (lm/w) | Luminous flux | CRI | Beam Angle | Driver Brand | |
T54-20W12 | 1198*38*38mm | 20W | 125PCS SMD2835 | 3000K/4000K 5000K/6000K | 130±10 | 2600±200lm | >80 | 120° | Tomcarline |
T54-30W12 | 1198*38*38mm | 30W | 125PCS SMD2835 | 3000K/4000K 5000K/6000K | 130±10 | 3900±300lm | >80 | 120° | Tomcarline |
T54-30W15 | 1498*38*38mm | 30W | 168PCS SMD2835 | 3000K/4000K 5000K/6000K | 130±10 | 3900±300lm | >80 | 120° | Tomcarline |
T54-40W15 | 1498*38*38mm | 40W | 168PCS SMD2835 | 3000K/4000K 5000K/6000K | 130±10 | 5200±400lm | >80 | 120° | Tomcarline |
Electrical datas
Type of current | AC 100~277V | Col or rendering i ndex Ra | >80 |
Power factor | >0.9 | Standard d eviation o f col or matching | <5 |
Start time ( 0.2s / 0 .5s / … ) | 0.1S | UGR | <27 |
Warm-up ti me to 6 0 % (1.5s / 2s / … ) | 0.5S | Available beam angles | 120° |
![]() |
